The TC/Analog Inputs to CAN Controller receives inputs from engine coolant, fuel and differential pressure sensors, engine temperature sensors, thermistors as well as thermocouples and is networked to a SAE J1939 or CANopen® based control system. Seven +5V references (10 mA) are provided to power the sensors. The 2 CAN ports are isolated from signal inputs and thermocouple inputs. It can be installed in control panels, industrial control automation systems, power generator set control systems, off-highway equipment, construction machines, and test equipment.
Applications
- CAN bus Networked Automation
- Precision Signal Conversion
- CAN bus Networked Vehicle Control Systems
- Test Equipment
- Machine Automation
| Technical Specifications: | TC/Analog Inputs to CAN Controller 4 Thermocouple, 7 Analog & 3 Signal Inputs 12 Vdc, 24 Vdc, 48 Vdc 2 CAN (SAE J1939) |
| Order Part Number: | P/N: AX181000 (TC/Analog Inputs to CAN Controller, SAE J1939, 250kBit/s) P/N: AX181000-03 (TC/Analog Inputs to CAN Controller, SAE J1939, 500kBit/s) P/N: AX181001 (TC/Analog Inputs to CAN Controller, CANopen®) |
| Power Supply Input: | 12V or 24Vdc nominal |
| Protections: | Reverse polarity protection Overvoltage protection is up to 120 V. |
| Communications: | 2 CAN ports Model AX181000, AX181000-03: SAE J1939 Model AX181001: CANopen® |
| Inputs: | 4 Thermocouple Inputs (Type J, K, or T) 7 Analog Voltage/Current Inputs (0-5V, 0-10V, 4-20 mA or 0-20 mA) 3 Analog or Digital Signal Inputs (0-5V, Thermistor, 0-20 mA, 4-20 mA, PWM, Frequency or Counter, Discrete) Refer to the Technical datasheet for details. |
| Enclosure: | High Temperature Nylon housing, TE Deutsch (P/N: EEC-5X650B) 4.03 x 4.25 x 1.68 inches 102.44 x 107.96 x 42.67 mm (L x W x H including integral connector) |
| Reference Voltages: | 7 provided +5V (10 mA) |
| Operating Conditions: | -40 to 85°C (-40 to 185°F) |
| Electrical Connections: | 48 pin TE Deutsch Connector (P/N: DT13-48PABCD-R015) or 48 pin Amphenol Face Plate Connector (P/N: ATM13-12PA-12PB-BM03), based on availability. Mates with: TE Deutsch P/N’s DT06-12SA Plug, DT 12 Way A Key DT06-12SB Plug, DT 12 Way B Key DT06-12SC Plug, DT 12 Way C Key DT06-12SD Plug, DT 12 Way D Key |
| Protection Rating: | IP67 PCB is conformal coated and protected by the housing. |
| Compliance: | CE marking |
| PDF Datasheet: |  Click icon for AX181000 PDF datasheet. Click icon for AX181001 PDF datasheet. |
